MMO anode protection tube
34
People watching this product now!
Description
| Diameter (mm) | Length L (mm) | Surface Area (m²) | Current Output (A/㎡) | Lifetime (years) | Application Scenarios |
|---|---|---|---|---|---|
| 25 | 1000 | 0.08 | 8 | 20-30 | Pipelines, Water Tanks, Pressure Vessels |
| 25 | 1000 | 0.08 | 48 | 20-30 | Pipelines, Water Tanks, Pressure Vessels |
| 32 | 1000 | 0.1 | 10 | 20-30 | Pipelines, Water Tanks, Pressure Vessels |
| 32 | 1000 | 0.1 | 60 | 20-30 | Pipelines, Water Tanks, Pressure Vessels |
*Other specifications and sizes can be customized according to customer requirements.
Substrate material: Titanium, meeting ASTM B338 Gr1 standard.
Chemical Composition
| Iron (Fe) | Carbon (C) | Nitrogen (N) | Hydrogen (H) | Oxygen (O) | Titanium (Ti) | Others |
|---|---|---|---|---|---|---|
| Maximum Content 0.20% | 0.08% | 0.03% | 0.02% | 0.18% | Remainder | 0.40% |
Coating System: Iridium Tantalum Coating, Ruthenium Iridium Coating
Enhanced Life Test Standard: NACE TM0108-2008.
Test Conditions
| System | Medium | Current Density (A/m²) | Temperature (°C) |
|---|---|---|---|
| Iridium Tantalum | 1mol/L Na₂SO₄ | 20,000 | 40 ± 5 |
| Ruthenium iridium | 1mol/L H₂SO₄ | 20,000 | 40 ± 5 |
